LED display 500*500L

LED screen specifications
model	p2.6	p2.8	p2.9	p3.9	p4.8
Display size	500*500
pixel pitch	2.604mm	2.840mm	2.976mm	3.906mm	4.807mm
pixel density	36864	30976	28224	16384	10816
pixel color	1R1G1B
Resolution	192*192	176*176	168*168	128*128	104*104
Chip packaging	SMD1415		SMD2020
Chip brand	kinglight
drive type	constant drive
driver chip	CHIPONE ICN2055
scan mode	1/24s can	1/22s can	1/28s can	1/16s can	1/1s can
Interface Type	HUB36P
Control System	NOVA STAR A7s
Display brightness	≥700cd/m²	≥800cd/m²		≥1000cd/m²
average power	280W/m²	250W/m²	280W/m²		250W/m²
Maximum power	650W/m²	600W/m²	650W/m²	650W/m²	600W/m²
refresh rate	≥3360Hz	≥2880Hz		≥1920Hz
grayscale	≥14B it
Protection class	IP30
